Color Removal with Ozone Water Treatment

Download Ozone Color Removal PDF

Color is an important concern for drinking water treatment plant operators since it is responsible for a significant number
of customer complaints about water quality.  In addition, many color problems are associated with fulvic, tannic or humic
acids.  Such color-causing compounds contain multiple conjugated double bonds, some of which are readily split by
ozone These compounds are also precursors to the formation of chlorinated organics in drinking water.  So their control
is important for more than aesthetic purposes.

Color in water is due to either the presence of particulate matter which scatters light, apparent color, or dissolved species
such as fulvic or humic acid, true color.  Filtration with membranes having 0.45 micron pores can effectively treat
problems associated with particulates, apparent color.  Even in situations with dissolved organics, true color, conventional
treatment processes (coagulation, flocculation, sedimentation and filtration) can remove a substantial portion of color.
Activated carbon can be used, but depending on the level of color, activated carbons can have a short life time in this
service.

Ozone is an effective oxidizer of color and won’t create chlorinated organic compounds.  Ozone for water treatment
applications is produced as a gas on site using an
ozone generator and then mixed with the water The use of ozone will
decrease the final amount of chlorine required.  For fulvic and humic substances ozone doses of 1-3 mg ozone/mg of
carbon can affect nearly complete removal of color. (1,2) Other studies have shown that 1 mg ozone/l can remove 10
color units (CU). (3)  It is important to understand a little about
color measurements.  We are referring to the Pt-Co color
scale.















Rakness (4) provides successful examples of ozone treatment of highly colored water.  In one case, 7-10 mg/l of ozone
with 10 minute hydraulic detention time (HDT) reduced water with 60-80 CU to 5-8 CU consistently.  In another case, 18
mg of ozone/l with a contact time of 10 minutes HDT reduced water with 135-140 CU and a small amount of hydrogen
sulfide to 5-8 CU.

At any dose there appears to be a threshold limit to the amount of color that can be removed using.  If the threshold color
limit is acceptable to the customers, further treatment may not be necessary.  If additional treatment is required, ozone
should be used as part of a treatment train to remove virtually all of the color.  The combination of ozone with activated
carbon has been shown to provide overall removal of color (90-95%).(5)

Design Considerations

The following are some design considerations for the use of ozone in color removal. (6) If only direct filtration is
employed, pre ozonation should be used.  If conventional treatment is employed (settling and filtration) the point of ozone
feed should be tested before settling, before filtration and two step ozonation.  The reaction of ozone with color appears
to have two phases, a fast phase and a slow phase.  The ozone dose should be designed to satisfy the first fast reaction
phase to most efficiently use ozone.  Roughly half of the ozone dose to reach the threshold limit will produce 60-70% of
the color removal.  Other methods can then be used to further reduce the color.  As with most ozone applications,
dynamic pilot studies should be used versus laboratory data for designing an ozonation system for color removal.

Spartan provides a range of
ozone generators and associated equipment which has been used for the removal of color in
a wide range of applications.


1.  Watts, C.D. 1985. Organic By-Products of Ozonation of Humic and Fulvic Acids. Proc. Intl. Conf. on the Role of Ozone in Water and Wastewater Treatment,
Edited by R. Perry and A. E. McIntyre. Selper Ltd., London
2.  Killops, S. D. 1986. Volatile Ozonation Products of Aqueous Humic Material. WTR. Res., 20:2:153
3.  Flogstad,H. & Odegaard, H.O. 1985. Treatment of Humic Waters by Ozone. Ozone Sci. Engineering., 7:2:121
4.  Rakness, K.L. 2005. Ozone in Drinking Water Treatment: Process Design, Operation and Optimization. AWWA Denver, CO
5.  Klimkina, N.V. 1987. An Evaluation of Treatment of colored Waters Using Oxidizing Sorption Method. Gigiena Sanitaria, 1:16
6.  Langlais, B., Reckhow, D. A. & Brink, D.R. eds. 1991. Ozone in Water Treatment: Applications and Engineering. Chelsea, MI: Lewis Publishers, Inc.
